RS-500 "Reference-Standard" Phono Pre-Amplifier

The RS-500 is a single-slot 500-series phono pre-amplifier built to a reference standard: accurate RIAA equalization, low noise, and a fully balanced output. It accepts a phono-level signal on RCA and delivers a balanced feed on the module edge connector.

The front panel carries a +10 dB gain switch and an 18 dB / octave rumble filter, each with a lamp that lights when engaged. Input capacitance is set internally to 50 or 100 pF to match the cartridge and tonearm.

Specifications

• Format: 500-series, single slot

• Input: phono level, RCA (L / R)

• Input impedance: 47 kΩ

• Input capacitance: 50pF, 100pF, 150pF, 200pF internally switchable

• Gain: 48 dB; 58 dB with +10 dB switch

• RIAA accuracy: ±¼ dB

• Rumble filter: 18 dB / octave, corner at 20 cps

• Output: fully balanced, module edge connector

• Cartridge type: moving magnet

• Output impedance, output stage, noise / THD, power: specification pending

Pending figures are not yet finalized. Measured performance will be published when testing is complete.
